Die RHF-11-Serie von 1kVA bis 10kVA (L) ist speziell für den Betrieb in Gebieten mit schlechter Stromversorgung konzipiert. Es verwendet ein Online-Doppelwandler-Design und digitale DSP-Steuerungstechnologie, stabilen und zuverlässigen Betrieb, hohe Effizienz, einfache Verwaltung. Es ist ideal für Geldautomaten, Banken und andere geschäftskritische Anwendungen. Der Benutzer kann den Ladestrom von 1A bis 6A je nach Anwendungsbereich einstellen.
-Online-Doppelkonvertierung verwirklichen
-Mikroprozessorsteuerung gewährleistet hohe Zuverlässigkeit
-Eingangsleistungsfaktor-Korrektur
-Ausgangsleistungsfaktor bis zu 0,8
-Großer Netzeingangsbereich (110 V - 300 V)
-Effizienter Umwandlungsmodus
-Kompatibler Generator
-Optional exquisite SNMP-Karte kann allein oder mit USB, RS232 zusammen perfekt zu überwachen sein
-Durch das Display, einfache Bedienung und umfassende zeigt den Status der Überwachung UPS
| High Frequency Single Phase Online UPS |
| Items | RHF-1101K (L) | RHF-1102K (L) | RHF-1103K (L) | RHF-1106K (L) | RHF-1110K (L) |
| Phase | Single Phase |
| Power Rating | 1000 VA / 800 W | 2000 VA / 1600 W | 3000 VA / 2400 W | 6000 VA / 4800 W | 10000 VA / 8000 W |
| Input |
| Input Voltage Range/Window | 55-150 VAC or 110-300 VAC at 50% load
85-140 VAC or 160-280 VAC at 100% load | 110-300 VAC (Based on load at 50%)
176-300 VAC (Based on load at 100%) |
| Frequency | 40Hz ~ 70 Hz | 46Hz ~ 54 Hz or 56Hz ~ 64 Hz |
| Power Factor | 100% load≧0.99 |
| Output |
| Output Voltage | 200/208/220/230/240VAC | 208/220/230/240VAC |
| Voltage Range (Battery Mode) | ± 1% |
| Frequency(Synchronization correction range) | 47~ 53 Hz or 57 ~ 63 Hz | 46Hz ~ 54 Hz or 56Hz ~ 64 Hz |
| Frequency (Battery Mode) | 50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz | 50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz |
| Surge Ratio | 3:1 |
| Harmonic Distortion | ≦ 3% THD (Linear Load)
≦6% THD (Nonlinear Load) | ≦ 3% THD (Linear Load)
≦5% THD (Nonlinear Load) |
| Transfer Time | AC to DC | 0ms |
| Inversion to Bypass | 4 ms (Standard ) | 0ms |
| Waveform(Battery Mode) | Pure Sine Wave |
| Efficiency |
| Bypass Mode | 88% | 88% | 90% | 92% | 93% |
| Battery Mode | 83% | 85% | 88% | 90% | 91% |
| Battery |
| Standard model | Battery Model | 12V / 9AH |
| Quantity | 2 | 4 | 6 | 16 | 20 | 16 | 20 |
| Max Charging Current | 1.0A（Max） | Preset:1.0 A ± 10%, Max.:2.0A ± 10% |
| Charging Voltage | 27.4VDC ± 1% | 54.7VDC ± 1% | 82.1VDC ± 1% | 218.4 VDC ± 1% | 273 VDC ± 1% | 218.4 VDC ± 1% | 273 VDC ± 1% |
| Long Run model | Battery Model | It ups to the User's requirement |
| Quantity | 2 | 3 | 4 | 6 | 6 | 8 | 16-20(Adjustable)** |
| The Max Charging Current | 1A/2A/4A/6A(Adjustable) | 1A/2A/4A/6A(Adjustable，6A(Only sutible for 16pcs batteries) |
| Charging Voltage | 27.4VDC ± 1% | 41.0VDC ± 1% | 54.7VDC ± 1% | 82.1VDC ± 1% | 82.1VDC ± 1% | 109.4VDC ± 1% | 273VDC ± 1%（When 20pcs batteries） |
| Apperance |
| LCD or LED Display | Load size, Battery power, Mains Supply Mode, Battery mode,Failure instruction |
| Alarm |
| Battery Mode | Sound every 4 seconds |
| Low Battery | Sound every second |
| Over-load | Sound every second |
| Fault | Continuous sounding |
| Physical Performance |
| Standard model | Size,WxDxH(mm) | 145 X282 X 220 | 145 X397 X 220 | 190 X421 X 318 | 190 x369x688 | 190 x442 x 688 |
| Net Weight(KG) | 9.8 | 17 | 27.6 | 61 | 74 | 66 | 75 |
| Long Run Model | Size,WxDxH(mm) | 145 X282 X 220 | 145 X397 X 220 | 190 x369 x 318 | 190 x442 x 318 |
| Net Weight(KG) | 4.1 | 6.8 | 7.4 | 12 | 16 | 18 |
| Operating Environment |
| Temperature & Humidity | Relative humidity 20-90 % and temperature 0- 40°C (No condensation ) | Relative humidity 0-95 % and temperature 0- 40°C (No condensation ) |
| Noise | less 50dBA @1 Meter | Less 55dBA @ 1 Meter | Less 58dB @ 1 Meter |
| Control Management |
| Smart RS-232 / USB | Support Windows® 2000/2003/XP/Vista/2008, Windows® 7/8, Linux, Unix, and MAC |
| SNMP(Option) | Power management support SNMP management and network management |
No | Model | Power Rating | Description | Product Size (mm) | Net Weight (KG) |
1 | RHF11-1KL | 800W | LCD Display,Battery 36V,Long-run Type | 282×145×220 | 4.1 |
2 | RHF11-2KL | 1600W | LCD Display,Battery 72V,Long-run Type | 397×145×220 | 6.8 |
3 | RHF11-3KL | 2400W | LCD Display,Battery 96V,Long-run Type | 397×145×220 | 7.4 |
4 | RHF11-6KL | 4800W | with LCD,Battery192V,Long-run Type | 369×190×318 | 12 |
5 | RHF11-10KL | 8000W | with LCD,Battery192V,Long-run Type | 442×190×318 | 16 |
No | Model | Power Rating | Description | Product Size (mm) | Net Weight (KG) |
1 | RHF11-1K | 800W | LCD Display,Battery 24V,，Built-in 7AH*2 | 282×145×220 | 9.8 |
2 | RHF11-2K | 1600W | LCD Display,Battery 48V,，Built-in 7AH*4 | 397×145×220 | 17 |
3 | RHF11-3K | 2400W | LCD Display,Battery 72V,，Built-in 7AH*6 | 421×190×318 | 27.6 |
4 | RHF11-6K | 4800W | LCD Display,Battery 192V,，Built-in 7AH*16 | 369×190×688 | 61 |
5 | RHF11-10K | 8000W | LCD Display,Battery 192V,，Built-in 7AH*16 | 442×190×688 | 66 |
1. The above Sizes and Weights are our standard type for your information. |
2. Customized products maybe with different sizes and weights. |
3. Product specifications are subject to change without further notice. |
Dieses Produkt ist weit verbreitet für Banken/Wertpapier-Clearing-Center, Registrierkassen, Geldautomaten, automatische Rolltore, PC-Terminals, Kommunikationsgeräte wie Faxgeräte, Telefone und SPC-Switches, Büroautomationssysteme, kommerzielle Infrastrukturen, mechanische Verarbeitungsgeräte, Transport, wissenschaftliche Forschung, Industrie, Verkehr, Eisenbahnen, Aufzüge, medizinische Geräte, Klimaanlagen, Radio und Fernsehen, Haushaltsgeräte, Beleuchtung, neue Energien und andere stromverbrauchende Anwendungen, die stabilisiert werden müssen.
