The high-frequency HHF online series is a product with strong adaptability and flexible configuration. It adopts a double-conversion pure online architecture. It is the most effective architecture design to solve all power problems. It is suitable for power grid problems: power outages and mains voltage overvoltage. High or too low, instant voltage drop or amplitude oscillation, high voltage pulse, voltage fluctuation, surge voltage, harmonic distortion, clutter interference, frequency fluctuation and other conditions can provide good solutions and provide safe and reliable user loads. Ground power supply guarantee; using advanced DSP digital control technology; effectively improving product performance and system reliability, and achieving higher power density and integrated miniaturization. At the same time, in order to fully meet the personalized needs of users, the high-frequency online series 1K-20K provides a very rich set of scalable functions that users can flexibly configure according to their needs
◆ Online double conversion,1/1 Phase pure sine wave online UPS.
◆ With smart design and high reliable, this system overall efficiency.
◆ Can be connected with all kinds of generators to save customers costs.
◆ Intelligent battery management, UPS charging current can be adjustable from 1-12A；
◆ Powerful overload ability with output short circuit protection technology which can high make sure the UPS reliability and system safety under critical status.；
◆ Compact size, smart design, high reliability.
Single Phase High Frequency 1-30KVA Online UPS (Transformer-less) |
Model | HHF-1101 | HHF-1102 | HHF-1103 | HHF-1106 | HHF-1110 | HHF-3310 | HHF-3315 | HHF-3320 | HHF-3330 |
Power Rating | 1KVA/800W | 2KVA/1.6KW | 3KVA/2.4KW | 6KVA/4.8KW | 10KVA/8KW | 10KVA/8KW | 15KVA/12KW | 20KVA/16KW | 30KVA/24KW |
Phase | Single Phase Input, Single Phase Output | Three Phase Input, Single Phase Output |
Input |
Voltage Range | 115-276VAC | 210-487VAC |
Frequency Range | 47~53Hz or 57~63Hz |
Factor | 0.99@ Rated voltage (100% load) |
Output |
Output Voltage | 208/220/230VAC/240V±1% |
Frequency Range | Synchronization with input (mains mode)50Hz±01Hz or 60Hz±01Hz (battery mode) |
Power Factor | 0.8 |
Transfer Time | 0ms |
Output Waveform | pure sine wave |
Over-load Ability | In the mains state, load <110%,30 minutes,110%, load <130%, 5 minutes,130%, load <10s |
Battery |
Long-run Machine | DC Volt | 36VDC | 72VDC | 96VDC | 192VDC | 16pcs（16-20pcs optional） |
Size | 145*282*220 | 145*397*220 | 190*415*318 | 190*442*318 | 250*592*576 | 250*815*826 |
Environment |
Humidity | 0-90% (no condensation) |
Noise | Less Than 45dB@ 1 Meter |
Control Management |
Smart RS-232 Optional USB | Support Windows ®2000/2003XP/Vista/2008,Windows ®/8,Linux.Unix,and MAC |
SNMP (Optional) | Power management Supports SNMP management and network management |
No | Model | Power Rating | DC Votlage | Product Size (mm) | Net Weight (KG) |
Single Phase Input and Single Phase Output (Tower Type) |
1 | HHF-1101 | 1KVA/0.8KW | 24VDC | 295*145*225 | 3.68 |
2 | HHF-1101L | 1KVA/0.8KW | 36VDC | 7.98 |
3 | HHF-1102 | 2KVA/1.6KW | 48VDC | 405*145*225 | 13.7 |
4 | HHF-1102L | 2KVA/1.6KW | 72VDC | 6.35 |
5 | HHF-1103 | 3KVA/2.4KW | 72VDC | 415*192*328 | 21.6 |
6 | HHF-1103L | 3KVA/2.4KW | 96VDC | 405*145*225 | 5.85 |
7 | HHF-1106 | 6KVA/4.8KW | 192VDC | 415*192*328 | 42.1 |
8 | HHF-1106L | 6KVA/4.8KW | 192VDC | 490*190*688 | 8.83 |
9 | HHF-1110 | 10KVA/8KW | 192VDC | 415*192*328 | 51.8 |
10 | HHF-1110L | 10KVA/8KW | 192VDC | 490*190*688 | 7.98 |
Single Phase Input and Single Phase Output (Rackmount Type) |
1 | HHF-1101-RM | 1KVA/0.8/1KW | 24VDC | 400*440*88 | 11.2 |
2 | HHF-1101L-RM | 1KVA/0.8/1KW | 36VDC | 440*325*88 | 6.8 |
3 | HHF-1102-RM | 2KVA/1.6/2KW | 48VDC | 440*405*88 | 17.05 |
4 | HHF-1102L-RM | 2KVA/1.6/2KW | 72VDC | 440*395*88 | 7.62 |
5 | HHF-1103-RM | 3KVA/2.4/3KW | 72VDC | 440*405*88 | 18.05 |
6 | HHF-1103L-RM | 3KVA/2.4/3KW | 96VDC | 440*395*88 | 7.95 |
7 | HHF-1106L-RM | 6KVA/4.8/6KW | 192VDC | 440*405*88 | 9.75 |
8 | HHF-1110L-RM | 10KVA/8/10KW | 192VDC | 10.74 |
1. The above Sizes and Weights are our standard type for your information. |
2. Customized products maybe with different sizes and weights. |
3. Product specifications are subject to change without further notice. |
This product is widely used for Bank/Securities clearing center, Cash register, ATM, Automatic shutter door, PC terminal user, Communication equipment such as fax machine, telephone and SPC Switch, Office automation system, Commercial infrastructure，mechanical processing equipment, transportation, scientific research, industry, transportation, railways, elevators, medical equipment, air-conditioning, radio and television, household appliances, lighting, new energy and other power-consuming occasions that need to be stabilized.
