1.Product Introduction

ZW-D series single phase intelligent static AC voltage stabilizer adopt the newest DSP operation and metering IC control technology, fastest AC sampling technology, effective values calibrating technology, current zero-crossing switching and fast compensating voltage stabilizing technology. They control several available silicon slice by special sequence to control the voltage connections, then to change the main voltage and voltage polar.

It is composed of insulation transformer, SCR modules, CPU control core, fast voltage stabilizing technology and safety protection device so that the voltage stabilizer accomplish non-contact control, safe, high efficient, energy conservation and environmental protection. It is the perfect match of transformer and SCR on/off switch.

2. Working Environment

ZW-D series voltage stabilizer should be used indoors. For outdoor use, customization is available, please contact our salesperson.

Ambient temperature: -15°C~+40°C

Relative humidity; ≤90%

Altitude: ≤1000m

No vibration or bumps in the installation site

There is no gas, steam, chemically deposited dust, dirt and other explosive and corrosive media that seriously affect the voltage and insulation.

·Large-screen LCD display

Using large LCD screen, can dynamically display the working voltage, working current, and various working conditions.

·Fast Response

Response time within 40 millisecond.

·Wide Input Voltage Swing Ranges

Input Range  can be customized from - ±15% to ±60%

·High Precision for the Output Voltage

Output Voltage Accuracy could be ±1% (±1% to ±5% adjustable)

·Multi-protection Design

Highly reliable and endurable design. With the protection of over-voltage, under-voltage ,over-load, short-circuit, automatic bypass.

This product is widely used for medical equipment, air conditioner, broadcast television, household appliances, building lighting equipment and other equipment which need stabilize voltage.
